6 Spiral Port Cannula – Black Power Handle

The 6 Spiral Port Liposuction Cannula with Black Power Handle is a blunt-tip aspiration cannula with six spiral ports, fitted with a black anodized handle. The anodized finish cuts the glare a polished handle throws back under operating lights, and colour-codes the debulking cannula against the finer patterns on the tray. It is listed under 6 Spiral Port Liposuction Cannulas, part of the Healermed Liposuction Cannulas and Accessories range.

Buyers also search for this instrument as a six port lipo cannula, a spiral port aspiration cannula, or a six hole liposuction cannula.

Anti-Glare Black Anodized Handle on a Six Spiral Port Cannula

Operating lights are bright and directional, and a polished steel handle reflects them straight back at the surgeon. An anodized black handle removes that reflection at the point closest to the eye line. Where a tray carries three and six port cannulas of the same diameter, colour on the handle is the fastest way to tell them apart mid-case.

How the Six Spiral Port Pattern Works

Six ports are stepped along the shaft and rotated around it, each one set further back and turned to a different side than the one before. It is the same spiral principle as the three port version, extended: twice the openings, spread over a longer stretch of shaft and covering more of the circumference.

The result is a wider draw band and a faster one. Each pass takes fat from six points at different depths and angles instead of three, so a given area is cleared in fewer passes and the tunnel it leaves is broader and less sharply defined. Adjacent passes overlap heavily, which is what keeps the transitions soft across a large surface.

The trade against the three port version is control. Six openings remove more per stroke, so there is less margin to stop at exactly the right point. That makes this the cannula for the debulking stage over large areas — abdomen, back, outer thighs — and makes the three port version the better choice once the shape is close and the work moves to blending. Many surgeons carry both and switch as the case progresses.

The distal tip is closed and rounded. It separates the plane by blunt dissection as the cannula advances, pushing vessels and nerves aside rather than dividing them, and the vacuum works through the six spiral ports rather than the end of the shaft.

Key Features

• ✔ Black anodized handle reduces reflected glare under operating lights
• ✔ Colour separates the six port debulking cannula from the three port finishing version
• ✔ Six ports stepped along the shaft and rotated — an extended spiral, not a cluster
• ✔ Wider draw band clears a large area in fewer passes
• ✔ Heavy overlap between adjacent passes keeps transitions soft across a big surface
• ✔ Closed blunt tip separates the plane without cutting vessels or nerves
• ✔ Deburred port edges for clean passage through fat
• ✔ One-piece German stainless steel shaft, fully reusable

Specifications

Clinical Applications

• Debulking large areas — abdomen, back and outer thighs
• High-volume body contouring where pass count needs to stay manageable
• Deep-layer work in larger patients with the 4.0mm to 6.0mm diameters
• Flanks and lower back with the 3.0mm to 3.5mm diameters

Material and Sterilization

The cannula is made from German stainless steel with a passivated surface that resists corrosion and pitting through repeated cleaning cycles. It is reusable and can be steam autoclaved at 134°C. Flush the lumen and all six ports with clean water immediately after use and dry fully before autoclaving. Because the ports sit at different points along the shaft, turn the cannula while flushing so water passes through each one, and check every opening under light — with six ports there are more places for residue to sit than on any other pattern in the range.

How to Choose

Choose the black handle for glare reduction or tray colour-coding; the shaft, ports and tip are identical to the other handle versions. If your cleaning protocol uses aggressive chemical agents, a plain steel handle will hold its appearance longer than an anodized finish. Diameter sets how much fat comes out per pass and length sets the reach. The six port pattern is built for area, so the 3.5mm to 5.0mm diameters in 30cm to 35cm are the core working range for abdomen, back and outer thighs. The 3.0mm in 25cm to 30cm suits flanks and smaller body areas. Below 2.5mm the six port pattern has little advantage over the three port version, so for arms, neck and superficial work choose the 3 spiral port cannula instead. Match the fitting to the syringe, vacuum line or handpiece already in your theater.

Why Buy Direct From the Manufacturer

Manufactured by Healermed Instruments, a surgical instruments manufacturer and exporter based in Sialkot, Pakistan. Factory-direct pricing removes the importer and distributor layer. Production runs under an ISO 13485 and FDA CGMP quality system, with ISO 9001 and CE Mark certification. OEM manufacturing and custom branding are available for distributor and brand-owner orders.

Related Instruments

Other fittings in the same cannula range:

• 6 Spiral Port Liposuction Cannula – Fixed Power Handle
• 6 Spiral Port Liposuction Cannula – Grooved Power Handle
• 6 Spiral Port Liposuction Cannula – MicroAire PAL Compatible
• 6 Spiral Port Liposuction Cannula – main product page
• 6 Spiral Port Liposuction Cannulas – all fittings
• 3 Spiral Port Liposuction Cannulas – the finer-control version

Frequently Asked Questions

What is a black handle six port cannula used for?

It is used to remove subcutaneous fat under vacuum during liposuction. The black anodized handle reduces light reflected back at the surgeon under operating lights, and makes the six port debulking cannula easy to distinguish from the three port version sitting beside it.

What is the difference between a 6 spiral port and a 3 spiral port cannula?

Both use the same spiral principle, with ports stepped along the shaft and rotated. The six port version has twice the openings over a longer stretch, so it clears fat faster across a wider band and suits debulking large areas. The three port version removes more slowly and gives more control, which suits blending and superficial work.

Is this cannula autoclavable?

Yes. The instrument is fully reusable and can be steam autoclaved at 134°C. Flush the lumen and all six ports with clean water immediately after use, turning the cannula so water passes through each one, then dry completely before sterilization. Inspect every opening each cycle, since the pattern depends on all six drawing evenly.

What is the minimum order quantity for bulk orders?

The minimum order quantity is agreed per order rather than set at a fixed number. Send us the sizes, fittings and quantities you need through the wholesale request page and we will confirm the minimum for that specification. This lets a small distributor start with a trial order and a larger importer scale up on the same terms.

Do you provide samples?

Yes. Samples are available on request and the buyer covers the shipping charges. Tell us the diameter and length you want to evaluate and we will confirm what can be sent. A sample also lets you run the anodized handle through your own sterilization protocol first.

Can I order a custom size?

Yes. Custom diameters, working lengths and port configurations are available on request in addition to the standard size grid. Send your specification through the wholesale request page and our production team will confirm what can be produced. Custom branding is also available for distributor and OEM orders.
