6 Spiral Port Cannula – Toomey Hub, 60cc

The 6 Spiral Port Liposuction Cannula with Toomey Hub is a blunt-tip aspiration cannula with six spiral ports, built to fit 60cc Toomey-tip syringes for syringe-assisted liposuction and fat harvesting. The wide, non-Luer Toomey opening lets aspirated fat move without the resistance a narrow taper creates. This fitting is made from 2.0mm (14G) upward. It is listed under 6 Spiral Port Liposuction Cannulas, part of the Healermed Liposuction Cannulas and Accessories range.

Buyers also search for this instrument as a 60cc Toomey six port cannula, a syringe liposuction cannula, or a spiral port fat harvesting cannula.

Toomey Hub Six Spiral Port Cannula for 60cc Syringes

A Toomey tip is a wide-bore syringe fitting, not a Luer taper. It exists because aspirated fat is thick and moves slowly through a narrow connector. This is the pairing where it matters most: a six port shaft can deliver more than any other pattern in the range, and only a wide hub lets that volume through without clogging.

How the Six Spiral Port Pattern Works

Six ports are stepped along the shaft and rotated around it, each one set further back and turned to a different side than the one before. It is the same spiral principle as the three port version, extended: twice the openings, spread over a longer stretch of shaft and covering more of the circumference.

The result is a wider draw band and a faster one. Each pass takes fat from six points at different depths and angles instead of three, so a given area is cleared in fewer passes and the tunnel it leaves is broader and less sharply defined. Adjacent passes overlap heavily, which is what keeps the transitions soft across a large surface.

The trade against the three port version is control. Six openings remove more per stroke, so there is less margin to stop at exactly the right point. That makes this the cannula for the debulking stage over large areas — abdomen, back, outer thighs — and makes the three port version the better choice once the shape is close and the work moves to blending. Many surgeons carry both and switch as the case progresses.

The distal tip is closed and rounded. It separates the plane by blunt dissection as the cannula advances, pushing vessels and nerves aside rather than dividing them, and the vacuum works through the six spiral ports rather than the end of the shaft.

Key Features

• ✔ Toomey hub matched to standard 60cc Toomey-tip syringes
• ✔ Wide bore is what lets a six port shaft work at its rated volume
• ✔ Six ports stepped along the shaft and rotated — an extended spiral, not a cluster
• ✔ Wider draw band clears a large area in fewer passes
• ✔ Heavy overlap between adjacent passes keeps transitions soft across a big surface
• ✔ Closed blunt tip separates the plane without cutting vessels or nerves
• ✔ Deburred port edges for clean passage through fat
• ✔ One-piece German stainless steel shaft, fully reusable

Specifications

Clinical Applications

• Syringe-assisted liposuction of the abdomen, back and thighs
• Fat harvesting for grafting in larger volumes
• Flanks and lower back with the 3.0mm to 3.5mm diameters
• High-volume syringe work with the 4.0mm and above diameters

Material and Sterilization

The cannula is made from German stainless steel with a passivated surface that resists corrosion and pitting through repeated cleaning cycles. It is reusable and can be steam autoclaved at 134°C. Flush the lumen and all six ports with clean water immediately after use and dry fully before autoclaving. Because the ports sit at different points along the shaft, turn the cannula while flushing so water passes through each one, and check every opening under light — with six ports there are more places for residue to sit than on any other pattern in the range.

How to Choose

The Toomey fitting starts at 2.0mm, and on a six port shaft the useful range starts higher still: 3.0mm to 5.0mm in 25cm to 35cm. For arms, neck and superficial work choose the 3 spiral port version instead.

Why Buy Direct From the Manufacturer

Manufactured by Healermed Instruments, a surgical instruments manufacturer and exporter based in Sialkot, Pakistan. Factory-direct pricing removes the importer and distributor layer. Production runs under an ISO 13485 and FDA CGMP quality system, with ISO 9001 and CE Mark certification. OEM manufacturing and custom branding are available for distributor and brand-owner orders.

Related Instruments

Other fittings in the same cannula range:

• 6 Spiral Port Liposuction Cannula – Luer Lock
• 6 Spiral Port Liposuction Cannula – Super Luer Lock
• 6 Spiral Port Liposuction Cannula – MicroAire PAL Compatible
• 6 Spiral Port Liposuction Cannula – main product page
• 6 Spiral Port Liposuction Cannulas – all fittings
• 3 Spiral Port Liposuction Cannulas – the finer-control version

Frequently Asked Questions

What is a Toomey hub six port cannula used for?

It is used with 60cc Toomey-tip syringes for syringe-assisted liposuction and fat harvesting in larger volumes. The wide non-Luer hub keeps aspirated fat moving instead of clogging, which matters most on a six port shaft that can deliver more than a narrow taper passes.

What is the difference between a 6 spiral port and a 3 spiral port cannula?

Both use the same spiral principle, with ports stepped along the shaft and rotated. The six port version has twice the openings over a longer stretch, so it clears fat faster across a wider band and suits debulking large areas. The three port version removes more slowly and gives more control, which suits blending and superficial work.

Is this cannula autoclavable?

Yes. The instrument is fully reusable and can be steam autoclaved at 134°C. Flush the lumen and all six ports with clean water immediately after use, turning the cannula so water passes through each one, then dry completely before sterilization. Inspect every opening each cycle, since the pattern depends on all six drawing evenly.

What is the minimum order quantity for bulk orders?

The minimum order quantity is agreed per order rather than set at a fixed number. Send us the sizes, fittings and quantities you need through the wholesale request page and we will confirm the minimum for that specification. This lets a small distributor start with a trial order and a larger importer scale up on the same terms.

Do you provide samples?

Yes. Samples are available on request and the buyer covers the shipping charges. Tell us the diameter and length you want to evaluate and we will confirm what can be sent. Testing a sample first confirms the hub seats correctly on the 60cc syringes you already stock.

Can I order a custom size?

Yes. Custom diameters, working lengths and port configurations are available on request in addition to the standard size grid. Send your specification through the wholesale request page and our production team will confirm what can be produced. Custom branding is also available for distributor and OEM orders.
